Description

Once again, the Dorado is available with a coil option. The new Dorado Comp features the same 37mm chassis as the Expert, but with a more set it and forget it vibe. The coil spring provides a smooth consistent feel 100% of the time with 0% of any hassle. On the damping side of things the ABS+ Damper offers a great adjustment range, terrific reliability, and easy serviceability. The Dorado Comp is built for riders who just want to ride and not sweat any of the small stuff.

  • 37mm 6000 Series aluminum stanchions with 6000 Series aluminum upper tubes
  • Aluminum upper and lower crown, and steerer
  • New 2-bolt drop crown features increased head tube length capability with 29" wheels
  • Inverted forks offer an incredibly smooth and consistent feel due to the constant lubrication of the bushings and seals and also provide a major increase in fore-aft stiffness with much longer bushing overlap compared to traditional fork designs
  • TPC adjustment with low speed compression, spring preload, rebound
  • Coil sprung, with up to five spring rates available separately
  • New direct mount fender is reversible, allowing for two orientations "moto" for increased front of fork coverage, bike" for increased behind fork coverage
  • 180, 190, 203mm internally adjustable travel

Specifications

These are the specifications for Item ID: FK0936

Color: Black
Weight: 3565
Crown race: 30
Steerer type: Straight
Brake type: Post Mount 203
Steerer tube length mm: 251
Axle to crown length: 602
Lockout switch: None
External adjustments: Rebound Damping","Low Speed Compression Damping","Coil Preload
Positive spring: Coil
Negative spring: Coil
Stanchion diameter: 37

Manitou

Manitou Dorado Comp Suspension Fork - 29", 203 mm, 20 x 110 mm, 57 mm Offset, Straight Steerer, Black, Gen 2

Manitou Dorado Comp Suspension Fork - 29", 203 mm, 20 x 110 mm, 57 mm Offset, Straight Steerer, Black, Gen 2

Regular price $1,299.99
Regular price $1,299.99 Sale price $1,299.99

Item ID: FK0936

Only 1 Items Left
