Description

Unleash the next level of racing performance with the latest innovation in Ohlins front suspension – the RXC34 m.1 XC fork. Equipped with their race-proven floating axle design, the RXC34 m.1 features a chassis with a stiff yet lightweight aluminum crown construction, providing precise steering and predictable performance. The RXC34 m.1 incorporates an all-new damper and updated air spring to further enhance speed and control on technical cross-country tracks. As part of the Öhlins XC suspension system, the RXC34 m.1 boasts a rider-friendly system to adjust air spring progressiveness and stroke. And with their race proven setting bank, you’ll be able to fine-tune the fork to your unique riding style and bike linkage.

  • Uses the new XC-optimized OTX14 damper that's been extensively designed to provide a slim, lightweight damper packed with technology
  • Highly adjustable with race-proven setting bank to match riding style and bike
  • Two-chamber air spring feature a large negative air chamber balanced with the damper’s characteristics in the three different ride modes – open, pedal, and lockout
  • Creates the initial movement required for superior traction while retaining best-in-class, predictable support when pushing hard
  • 12 clicks of LSC and 12 Clicks of rebound
  • Up to 5 positive volume spacers to adjust progressiveness (depending on travel)
  • Up to 7 negative spacers to adjust initial sensitivity
  • 15mm x 110mm boost floating thru-axle axle design

Specifications

These are the specifications for Item ID: FK5129

Color: Black
Weight: 1598
Crown race: 40
Steerer type: Tapered
Brake type: Post Mount 180
Axle to crown length: 531
Lockout switch: Crown
External adjustments: High Speed Compression Damping","Low Speed Compression Damping","Rebound Damping
Positive spring: Air
Negative spring: Air
Stanchion diameter: 34

Ohlins

Ohlins RXC34 m.1 Suspension Fork - 29", 120mm, 15mm x 110mm, 44mm Offset, OTX14 Damper, Air Spring, Black

Ohlins RXC34 m.1 Suspension Fork - 29", 120mm, 15mm x 110mm, 44mm Offset, OTX14 Damper, Air Spring, Black

Regular price $1,350.00
Regular price $1,350.00 Sale price $1,350.00

Item ID: FK5129

Only 5 Items Left
