Description

The Karate Monkey features updated, progressive trail geometry, our custom trumpet tubeset and Surly’s Gnot-Boost rear dropout system. Available in a variety of colors, with multiple drivetrain and wheel size configurations.

100% Surly Chromoly steel frame and fork; double-butted main triangle and 44mm headtube
The tubeset uses the same trumpet tubes found on Instigator 2.0 frame
Adjustable rear dropouts with 145mm Gnot-Boost spacing. Works with 142, 148 12mm thru, as well as 135mm w/ 10/12 washer
Internal dropper seatpost routing with 30.9mm seat tube ID
Clearance for 29 x 2.55 or 27.5 x 3 tires

Prop 65 Text: WARNING Handling this product will expose you to chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.

Specifications

These are the specifications for Item ID: FM1537

Color:	Peach Salmon Sundae
Brake type:	Disc
Rear axle:	12mm Thru x 145mm
Tt effective:	660
Fork type:	Rigid
Fork material:	Steel
Frame material:	Steel
Frame type:	Rigid
Platform:	Karate Monkey
